Down Light Slim Square
Low wattage square LED light Downlight is a perfect replacement to CFL Downlight. A very high quality High sink take care of Heat dissipation.
Low wattage square LED light Downlight is a perfect replacement to CFL Downlight. A very high quality High sink take care of Heat dissipation.
Application Area: In Door Lighting Applications, Office Lighting, Lobby, and Corridor.
| S. No. | Parameters | Model No. - SSDL-8W-4IN-CW-S | Model No. - SSDL-12W-6IN-CW-S | Model No. - SSDL-18W-8IN-CW-S |
|---|---|---|---|---|
| 1 | Wattage | 8W | 12W | 18W |
| 2 | Input Voltage | 220-240 Vac | 220-240 Vac | 220-240 Vac |
| 3 | Operating Voltage | 110-265 Vac | 110-265 Vac | 110-265 Vac |
| 4 | Power Factor | >0.95 | >0.95 | >0.95 |
| 5 | Efficency | >90% | >90% | >90% |
| 6 | CRI | >80 | >80 | >80 |
| 7 | CCT | 3000K/4000K/6000K | 3000K/4000K/6000K | 3000K/4000K/6000K |
| 8 | Lumen Output | 960 Lumens (+- 10%) | 1440 Lumens (+- 10%) | 2160 Lumens (+- 10%) |
| 9 | System Efficacy | 120 Lumen Per Watt | 120 Lumen Per Watt | 120 Lumen Per Watt |
| 10 | Viewing Angle | 160 Degree | 160 Degree | 160 Degree |
| 11 | Operating Temperature | (-10 degree to 40 Degrree centigrade). | (-10 degree to 40 Degrree centigrade). | (-10 degree to 40 Degrree centigrade). |
| 12 | Protection | Auto Cut Low & High Voltage. | Auto Cut Low & High Voltage. | Auto Cut Low & High Voltage. |
| 13 | Surge Protection | 4KV Internal | 4KV Internal | 4KV Internal |
| 14 | Heat Sink | Aluminium | Aluminium | Aluminium |
| 15 | IP Grade | IP 20 | IP 20 | IP 20 |
| 16 | Mounting Type | Recessed Type | Recessed Type | Recessed Type |
| 17 | Dimension | 113 mm X 113mm (Cut Out Dia); x 118 mm x 118mm Outer Dia | 160 mm x 160 mm (Cut Out Dia); x 168 mm x 168 mm Outer Dia | 223 mm x 223 mm (Cut Out Dia); x 234 mm x 234 mm Outer Dia |
| 18 | Weight | 200 Grams. | 300 Grams. | 350 Grams. |
